    1.5KW 2.2KW 4KW Solar Inverter Single Phase Input Single Phase Output

    Ask Lasest Price
    Brand Name : VEIKONG
    Model Number : VFD500M-PV
    Certification : CE
    Price : Negotiable
    Payment Terms : Western Union, T/T, L/C, D/A, D/P, PayPal
    Supply Ability : 15000pcs per Month
    Delivery Time : 3 days, depend on the order quantity
    • Product Details
    • Company Profile

    1.5KW 2.2KW 4KW Solar Inverter Single Phase Input Single Phase Output

    1.5KW 2.2KW 4KW Solar Inverter Single Phase Input Single Phase Output


    1.5KW 2.2KW 4KW Single Phase Input Single Phase Output Solar Pump Inverter


    Product Feature:


    1. Support Maximum MPPT efficiency 99%


    2. Special solar MPPT mode and PID mode


    3. Support GPRS remote control


    4. Support IM and PM pump


    5. Support dry run protection



    Eletrical Specification


    220V380V
    Max input DC voltage450V810V
    DC voltage range150~450VDC250~810VDC
    Recommended input mppt voltage305V530V
    MPPT efficiency>99%
    Rated output voltage1/3-phase 220VAC3-phase 380-480VAC
    Output frequency range50/60Hz
    Max efficiency of the machine99%
    Ambient temperature range-10 °C~50 °C, derating if the temperature is above 40 °C
    Cooling methodAir cooling
    Protection degreeIP20/IP21
    AltitudeBelow 1000m; above 1% for every additional 100m.
    StandardCE/ROHS

    Product Model


    Drive modelMax DC input current (A)Rated output current (A)Applicable water pump (kW)
    VFD500M-40T00075-PV4.22.50.75
    VFD500M-40T00150-PV6.13.71.5
    VFD500M-40T00220-PV7.152.2
    VFD500M-40T00400-PV16.59.44
    VFD500M-40T00550-PV23.9135.5
    VFD500M-40T00750-PV30.6177.5
    220V single phase or three phase level
    VFD500M-20T00075-PV6.74.50.75
    VFD500M-20T00150-PV9.971.5
    VFD500M-20T00220-PV14.1112.2
    VFD500M-20T00400-PV22.6174

    Product Details



    FAQ:


    1. How to use a float in the water tank to stop the pump if the tank is full?


    Use float switch to short DI 1 and com.


    2.1 How to set minimum frequency 25hz and maximum 50HZ?


    Set P47.05=25HZ and 47.06 to some time and 47.07 to some time


    3. 1 If pump is 60HZ frequency ,how to set max frequency?


    Notice:If your motor rated frequency is 60HZ you should set P01.06=P01.08=P11.05=60HZ.
