IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT

Shenzhen Veikong Electric Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT from wholesalers

    Buy cheap IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT from wholesalers
    • Buy cheap IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT from wholesalers
    • Buy cheap IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT from wholesalers

    IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT

    Ask Lasest Price
    Brand Name : VEIKONG
    Model Number : VFD500-PV
    Certification : CE
    Price : Negotiable
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 15000pcs per Month
    Delivery Time : 3 days, depend on the real quantity
    • Product Details
    • Company Profile

    IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT

    IP20 380V 2.2KW 3HP Solar Pump Inverter With High Efficiency MPPT


    Product Features:


    1. Accept dual input: DC / AC


    2. Built in high precision PV array maximum power point tracking MPPT algorithms


    3. Weak sunshine function


    4. Dry running mode monitoring, treatment


    5. Tank water level control


    6. LCD/LED display the real time situation and parameter of system


    7. Built-in full protection and disgnostic mechanism


    8. Fast installation design, no need extra maintenance


    Technical Specifications



    220V

    380V

    Max input DC voltage

    450V

    810V

    DC voltage range

    150~450VDC

    300~810VDC

    Normal working DC voltage

    260V-400V

    400V-650V

    Recommended input mppt voltage

    330V

    550V

    MPPT efficiency

    >99%

    Rated output voltage

    1/3-phase 220VAC

    3-phase 380-480VAC

    Output frequency range

    50/60Hz

    Max efficiency of the machine

    99%

    Ambient temperature range

    -10 °C~50 °C, derating if the temperature is above 40 °C

    Cooling method

    Air cooling

    Protection degree

    IP20/IP21

    Altitude

    Below 1000m; above 1% for every additional 100m.

    Standard

    CE/ROHS


    Model Range


    Drive model

    Max DC input current (A)

    Rated output current (A)

    Applicable water pump (kW)

    VFD500M-40T00150-PV

    6.1

    3.7

    1.5

    VFD500M-40T00220-PV

    7.1

    5

    2.2

    VFD500M-40T00400-PV

    16.5

    9.4

    4

    VFD500M-40T00550-PV

    23.9

    13

    5.5

    VFD500M-40T00750-PV

    30.6

    17

    7.5

    VFD500-40T00150-PV

    6.1

    3.7

    1.5

    VFD500-40T00220-PV

    7.1

    5

    2.2

    VFD500-40T00400-PV

    16.5

    9.4

    4

    VFD500-40T00550-PV

    23.9

    13

    5.5

    VFD500-40T00750-PV

    30.6

    17

    7.5

    VFD50040T01100-PV

    39.2

    25

    11

    VFD500-40T01500-PV

    49.0

    32

    15

    VFD500-40T01850-PV

    57

    37

    18.5

    VFD500-40T02200-PV

    69

    45

    22

    VFD500-40T03000-PV

    91

    60

    30

    VFD500-40T03700-PV

    114

    75

    37

    VFD500-40T04500-PV

    146

    90

    45

    VFD500-40T05500-PV

    190

    112

    55

    VFD500-40T07500-PV

    237

    152

    75

    VFD500-40T09000-PV

    273

    176

    90

    VFD500-40T11000-PV

    319

    210

    110

    VFD500-40T13200-PV

    389

    253

    132

    220V single phase or three phase level

    VFD500-20T00075-PV

    6.7

    4.5

    0.75

    VFD500-20T00150-PV

    9.9

    7

    1.5

    VFD500-20T00220-PV

    14.1

    10.6

    2.2

    VFD500-20T00400-PV

    22.6

    17

    4

    VFD500M-20T00150-PV

    9.9

    7

    1.5

    VFD500M-20T00220-PV

    14.1

    10.6

    2.2


    Product Application


    IP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPTIP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPTIP20 380V 2200w 3HP Single Phase Solar Pump Inverter With High Efficiency MPPT
